OE-C004— C-EPS for UTV&ATV
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Information
Typical application：Medium-sized unmanned sightseeing vehicle, driverless UTVs.
Parameters
| Structure type | C-EPS |
| Maximum supply current | 80A@DC12V |
| Operating voltage | DC12V |
| Output torque |
C004: 54Nm C004C: 61Nm |
| teering shaft maximum load (reference) |
850Kg |
| Degree of protection | IP67 |
| Sensor type | TAS |
| Angular resolution | 0.1° |
| Angle control accuracy | 1° |
| Angular velocity control accuracy | <3°/ s |
| Response time | <100ms |
