22KW AC to DC On Board Battery Charger
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
|
OBC
|
|||
|
Structure size and weight
|
Dimensions: 346mm×342mm×168mm
Weight: 20KG
|
||
|
AC input
|
High voltage output
|
||
|
Input voltage range
|
85-264Vac
|
Output voltage range
|
200-420Vdc
|
|
Rated input voltage
|
220 Vac
|
Rated output voltage
|
366Vdc
|
|
Input frequency range
|
45-65 Hz
|
Output power
|
6.6 kW max
|
|
DCDC
|
|||
|
High voltage input
|
Low voltage output
|
||
|
Input voltage range
|
200-450Vdc
|
Output voltage range
|
13.8Vdc
|
|
Rated input voltage
|
366Vdc
|
Output rated voltage
|
13.8±0.3Vdc
|
|
Maximum input current
|
11A
|
Output power
|
1.5 kW
|
