6.6KW 48V 72V ACDC Converter EV On Board Battery Charger OBC
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Parameters
|
6.6kw 72V OBC
|
Specifications
|
|
|
Spec
|
Type
|
6.6KW air-cooled car charger
|
|
Model
|
RA6P6072
|
|
|
Output Voltage
|
72V
|
|
|
charging mode
|
Response mode
|
|
|
Input
|
Input voltage
|
90V-256V
|
|
Frequency
|
50Hz
|
|
|
Inrush current
|
≤30A
|
|
|
Input power factor
|
≥0.99（@220Vin,Pomax）
|
|
|
Output
|
Output power
|
6.6KW
|
|
Range of output voltage
|
0V-95V
|
|
|
Range of output current
|
0A-90A
|
|
|
Voltage regulation accuracy
|
≤1%
|
|
|
Voltage ripple coefficient
|
≤1%
|
|
|
Current regulation accuracy
|
≤5%
|
|
|
Output response time
|
≤5S
|
|
|
Typical efficiency
|
≥94%
|
|
|
Output voltage of low voltage module
|
12V±1V
|
|
|
Output power of low voltage module
|
2W
|
|
|
Output voltage ripple coefficien of low voltage module
|
≤1%
|
|
|
Working noise
|
≤60dB
|
|
|
Environment
|
Working temperature
|
-40～65℃
|
|
Storage temperature
|
-40～95℃
|
|
|
humidity
|
5%~95% non-condensing, no condensation
|
|
|
Level of IP
|
IP67(without fan)
|
|
|
The cooling function
|
Forced air cooling
|
|
|
Communication function
|
CAN bus control
|
|
|
Charge function
|
It can be charged normally after receiving the charging command; the charger is in standby state without command
|
|
|
Other
|
weight
|
6Kg±0.3Kg
|
